3eFlow offers the new standard in hot water distribution. Independently validated by the Building Research Establishment it offers up to 70% energy saving on heat network when compared to conventional installation.

Why 3eFlow?

-Enables lower temperature distribution network

-Reduced heat losses

-Increased efficiency

-Smaller plant size

-Reduced consumption

-Enables use of other low carbon solutions such as solar

-Enabling next generation Heat Interface units

References:

Building Research Establishment Watford

Vattenfall, one of Europe’s largest producers and retailers of electricity and heat, with over two million heat customers across Europe, has entered the UK market to provide customers with reliable, low carbon and affordable heating and cooling.

Vattenfall Heat UK Ltd, in partnership with cities and regions throughout the UK are driving the transformation towards fossil-free, smart energy systems. Heat is a core business for the Vattenfall Group, and in establishing itself in the UK aims to bring its experience in developing, constructing, and operating heat and distribution networks from Sweden, Germany, and the Netherlands.

Regin wants to challenge the building automation industry with our sustainable solutions for reduced energy consumption. We develop solutions for building automation as well as energy distribution for heat networks. Our goal is to make Regin your leading supplier of solutions that contribute to reduced energy consumption and sustainable development.

Our offer: Complete solutions to control heat networks, heating substations and metering

Regin offers complete solutions to control heat networks, heating substations, energy metering and SCADA software, including controllers, sensors, valves and actuators for heating substations as well as indoor control.

Why Regin?

• Enables sustainable solutions for reduced energy consumption
• Smart solutions using a robust technology for monitoring and control of the heat network
• Flexible range delivering both to small and large scale solutions

References:

Public and private energy operators, Schenker, E.ON, Vattenfall, amongst others.

Againity develops and constructs robust and high-performing ORC turbine systems. The ORC converts low temperature heat (> 90˚C) into sustainable and local electricity pro­duction from 50 kWe to 2.5 MWe. Common heat sources include biomass boilers, waste incinerators, biogas boilers, and waste heat from gas turbines or diesel generators.

Againity’s system is based on the long-known Organic Rankine Cycle (ORC) technology. The technology includes a steam turbine set in motion by the pressure of a vaporized internal working medium. The rotating turbine drives a generator that produces electricity. The ORC system is delivered pre-assembled and connected with two pipes to the heat source and two pipes to the cooling water (e.g. district heating return flow or air cooling system).

Why Againity?

Thanks to the unique design of Againity’s patented turbine and the low number of moving parts in the system, a high-quality product can be offered. This minimizes the need for service (normally less than 1 day/year) which significantly shortens the payback time compared to similar technologies.

References

Sales of 20+ ORC turbines and additional equipment including boilers and cooling systems within Scandinavia.

Our customers include, among others:

• E.ON
• Solör Bioenergi
• Ragn-Sells
• Ystad Energi
• Eidsiva Energi

Akron provides low carbon heat with locally produced fuels for agricultural and industrial clients. Our solid biofuel air heaters are suitable for all types of heated air processes. We enable our clients to both reduce energy costs and environmental impact. It makes both economic and environmental sense to use solid biofuels as part of a sustainable energy mix for heating, in terms of production as well as a profitable revenue stream.

Our offer: Flexible heat generation with solid biofuels and heavy fan solutions for industries

We offer flexible heat generation using solid biofuels suitable for agricultural and industrial clients. Our product range covers all agricultural and industrial grain and bio-fuel handling needs, from transportation and loading solutions to drying, storage and burning with a state-of-the-art operational control.
We also offer heavy-duty fan solutions for industrial and drying processes, as well as high-output particle separation fans and other special applications. Our in-house research, development and manufacturing enable us to optimise to each customer’s needs.

Why Akron?

• Solid biofuel air heaters is a smart solution for all agricultural and industrial heated air processes
• In-house research, development and manufacturing enable us to optimise to the needs of our customers
• Our dryer, storage and transport solutions reduce fuel loss and increase the reliability of fuel supply

Range:

200 KW – 1 MW

References:

Bio-Nordic. Contact: James Haigh – www.bio-nordic.co.uk

Bio-Nordic Ltd is a UK based consulting distributor specialising in the planning, design, specification, supply, integration and lifetime support of renewable and low emission energy technologies and pipeline networks, predominantly sourced from the Scandinavian regions.

Bio-Nordic has built upon the 30+ years of work carried out by ÄFAB, a highly respected Swedish consultancy working predominantly within biomass combustion.

Our experience spans all building services and renewables technologies, and a range of scales from kW’s for domestic dwellings through to MW’s for large scale commercial and industrial application.

Our offer: Scandinavian sustainable energy solutions

• Concept and Outline Planning (in conjunction with architectural considerations)
• Energy advisory and assessment (building fabric performance and energy demand)
• Feasibility Studies and Lifecycle Analysis (Source and Distribution)
• Design Development and Specification preparation.
• Government incentive procurement. (Renewable Heating Incentive specialism)
• Installation, Service and Maintenance: Through close partnership with leading manufacturers and authorised, experienced building services and rural engineering contractors, Bio-Nordic provides a full project delivery and renewables system commissioning and support service, underpinned by factory and field training.

Why Bio-Nordic?

Bio-Nordic has been a leading specifier and supplier of renewables systems in the UK market since the mid 90’s, gaining a wealth of experience and proven project track record.

Close engagement with manufacturers and contractors alike ensures free-flowing knowledge transfer and quality site procedures protecting assets and optimising plant performance and longevity.

References:

Our manufacturers are Akron, Ariterm, Effecta, Elgocell, OsbyParca, ESBE, GotFire, JM Stoftteknik, MAFA, Petro Bio, Powerpipe, and WTS. We have worked on projects such as Lakes Free Range Egg Company, Park Foot Holiday Cottages, Yorkshire Riding Centre, N.Milford Hall

We want it to be easy to choose bioenergy as an energy solution. At biOptima, we deliver completely customised bioenergy plants for a reliable production of heat as warm or hot water or steam. With rising electricity prices and oil taxes, bioenergy has become a secure and smart option to conventional solutions.

Our offer: Customised bioenergy plants

biOptima offers quality assured, CE-labelled and turnkey bioenergy plants which are customisable to your needs and to lower your energy costs. Choose between various bioenergy fuels or inputs and physical configurations of your plant, always complete with performance and emission guarantees.

How you will use biOptima’s products is up to you; buy, lease or buy ready heat from a biOptima plant. We facilitate an environmentally friendly choice that is durable and low in operational and spare parts costs. Our mobile bioenergy plants for burning wood pellets and wood chips include heating stations, platforms and installation.

Why biOptima?

• Get a turnkey solution customised to your needs
• Full control of your energy supply with guaranteed performance and emissions levels
• Secure and smart option to conventional heat solutions

Range:

0,5 – 5 MW

References:

Swedish Armed Forces, Polyprojekt AB, Tjintokk AB, CCT AB and municipalities

Bizcat is a strategic energy consultant focused on the heat market for some 20 years, including managing highly recognised international DHN feasibility studies in UK, Canada, US and New Zealand. During our 10 years of UK presence we have provided strategic low carbon energy advisory support, regional and local economic development, district energy masterplan and feasibility studies, low heat density R&D as well as studies on building compliance for DHN and heat pumps in England, Scotland and Wales.

Our offer: Strategic energy advisor and business case consultant

Bizcat’s entry to any project or study is based on our ‘demand-to-supply’ perspective, meaning heat supply options need to match heat demand and not vice versa. Defining the actual and future heat (or cooling) demand, especially the system designing peak demand, is the most important part of all studies having a considerable impact on sizing, design and costs. We know ways for substantial reduction in capital and operational expenditures for heat supply systems (generation, distribution and building interface) by marginal changes in building operation.

With the ‘demand-to-supply’ approach the heat and cooling solutions will be dependent on demand structure and options of local energy sources. Bizcat always strives for making low carbon heating solutions becoming drivers for developing the local economy and well-being of the residents.

With 10 years presence on the UK heating market, Bizcat have been collaborating with several UK and Swedish energy and engineering consultancies (e.g. Atkins, Arup, Locogen, Natural Power, FVB, Nordic Heat and ÅF). Over time we have built a network of associate specialists and collaboration partners (investment and financing, business models, deep data analysis and AI etc.) making it possible for us to customise expert teams for each project. Our long and deep UK experience has provided us with an insight of building improvement potential that can revolutionise the entire heat market in the UK.

Why Bizcat?

• Our understanding and experience of the specific UK heat market
• ‘Demand-to-supply’ and technology independence (DHN, heat pumps, biomass)
• Small building management changes making huge size and cost reductions
• Customised project teams based on our network of specialists and partners

References:

Heat Energy Masterplans and Feasibility studies: NE Lincolnshire, Allerdale BC, South Gloucestershire Council, Falkirk Council, Edinburgh Council, Scottish Government, Britain’s Energy Coast West Cumbria, Neath Port Talbot CBC, Swansea Council, Swindon BC
Local Economic Development: Allerdale BC, Cheshire & Warrington LEP, Britain’s Energy Coast West Cumbria
Heating system R&D: Heat Profile Flattening, Social Housing Heat Network (DECC/SBRI)

With a track record of 30 years within energy management, Bywall Consulting is the third party expert to go to when you are designing a heat network.

Our offer: Energy consulting services

Bywall Consulting’s specialty is to analyse and design a business case including everything from customer benefit to heat production. Our areas cover environmentally friendly systems, financial asepcts such as risk analysis and corporate planning and technical design. We provide early stage advice to investors and stakeholders and identify the unique selling points for each project.

References:

Dala Energi – small scale District Heating system with 99 % renewable energy supply.
BIODAL – Joint venture between Energy company and Private large scale Saw mill, boiler fired with 100% renewable energy. Annual 35 GWh. Gävle Energi – Large scale DHC with CHP and industrial waste energy

Internationally known, Cetetherm are the “Go To” experts and leading manufacturer of solutions for District Heating and Cooling products. Energy efficiency and sustainability are key to the Cetetherm philosophy. “Swedish engineering – Creating the Right Climate”

Our offer

A large range of compact and energy efficient Heat Interface Units (HIU) offering the lowest return temperature on the market ; Cetetherm Mini City, Mini ECO and the Micro range. Cetetherm continually innovates ; besides finding the best solution to save water and energy, we combine our HIU with new connectivity technologies for remote monitoring and control.

The Cetetherm Maxi is an extremely large range of heating & cooling substations with multiple possibilities and applications, in capacities 50kW – 10MW (unlimited for bespoke units). Our Maxi units are pre-assembled, pre-mounted, tested, wired and verified – ready to go, offering the most energy-efficient solution thanks to optimal heat recovery and low return temperatures.
Supervision is available via customer`s laptop, smartphone or from the control panel of the Cetetherm’s IQHeat control unit. Now available with a cloud connection : Maxi IQHeat-IQCloud.

Why Cetetherm

• Reliability : We have provided customers with hot water and heating since 1932 as one of the original leaders in district heating networks
• Operators and energy companies can benefit from our optimized low return temperature solutions, connected to a building management system
• More than ¼ million HIUs and 100,000 substations supplied worldwide
• Cetetherm is at the customer’s side from concept up to 5 star After-Sales service

Crossbreed provides a digital ecosystem for the energy sector that comprises of both services and infrastructure. By providing a complete ecosystem of smart energy services, including a multitude of algorithms that work autonomously and in symbiosis, we bring tangible financial, environmental and operational improvements in networks, buildings and homes.

We call it the Crossbreed Energy OS.

Our offer: AI managed Energy Services in one eco-system

The Crossbreed ENERGY OS portfolio:

• AI-operated dynamic supply temperature optimisation based on customer heat demands
• Operational Demand Side Management tools to optimize and control the demand behavior of the network and to lower return temperatures
• Cloud-based energy efficiency service for buildings with real-time optimisation of heat consumption for reduce energy usage
• Data driven AI analytics for advanced decision-making support

Why Crossbreed ENERGY OS?

By using the Crossbreed ENERGY OS, energy operators will gain benefit and support in all parts of the intelligent energy value chain.

• Supply Management – Lower supply temperature with 2-10 degrees
• Network Management – Lower return temperature with 2-3 degrees, reduce peak heat demand by 10-17% and increase capacity for network expansion
• Buildings – Lower energy use by 10-12%
• Analysis – Support operational and financial decision-making, and make internal resources more efficient

References

E.ON Sweden

DEVCCO has been the driving force in several of the world’s largest and most pioneering district heating, cooling and multi utility developments for the last two decades. Few consulting firms can match DEVCCO’s achievements when it comes to international projects in the energy and utility industries.

Our offer: Energy consulting and project management

Our heat network consulting services include project development, business strategies and restructuring, feasibility studies, energy master plans and project management and governance. We also act as project manager during the entire development of a network.
DEVCCO has at its disposal a variety of models for safe and efficient calculations of energy balances, cash-flow and financial key figures, risk profiles and distributions. Along with the computational models, DEVCCO also uses a well-proven tool for methodical and structured risk management in the development of district energy projects.

Why DEVCCO?

• Whatever circumstances of the existing systems in place, we offer owners and operators improved performance of the heat network

References:

EuroHeat and Power, King Abdul Aziz Road Project, Öresundskraft AB, UNDP, City of Stockholm, NUON and more.

We create value for people, planet and business by connecting, digitizing and optimizing buildings.

Our offer:

Egain is a leading technology SaaS company within digital control and energy optimization of residential and government buildings. We develop IoT solutions, mobile apps, and AI-based software that visualizes building opportunities and optimizes the energy consumption leading to lower energy consumption, improved buildings’ environmental footprint, optimized living comfort and, increased property valuations. Egain was founded in 2003 with HQ in Kungsbacka, Sweden, and is currently serving more than 5,500 buildings and 300,000 apartments in 11 countries.

Why Egain?

• Increased property value: Create sustainable value in your real estate portfolio by decreasing energy expenses and increasing control and efficiency in management of your residential and public buildings.
• Digitization made easy: A quick and cost-effective road map to the digitization journey for owners, managers and developers of residential and public real estate.
• Updated and in control: Gain control of your buildings enabling a more efficient management through insights that takes your property management to the next level.
• A better and more sustainable world: Decreases the carbon footprint from residential and public buildings and contribute to a better and more sustainable world.

References

Victoria Park (Sweden): https://www.egain.io/customer-stories/increased-property-value-reduced-environmental-impact/

Halmstads Fastighets (Sweden): https://www.egain.io/customer-stories/high-energy-savings-intelligent-heating/

Studentenwerk Leipzig (Germany): https://www.egain.io/customer-stories/more-consistent-indoor-climate-significant-reduction-of-co2-emissions/

Gersageparken (Denmark): https://www.egain.io/customer-stories/great-savings-good-comfort/

Łomża Housing Cooperative (Poland): https://www.egain.io/customer-stories/aims-and-objectives-2/

Ekström & Son is one of Northern Europe’s leading firms in engineering, manufacturing and servicing of heat exchangers and pressure vessels for the process and power industry. We are committed to providing technology and products that help our clients to be more energy efficient. The energy savings in industrial activity we can achieve do not only lower operational costs, but also the usage of fossil fuels, thereby emissions of greenhouse gases.

Our offer: Tubular heat exchangers and Smart Loop backflush valve

We provide our clients with Smart Loop backflush valves and HelixChanger™ tubular heat exchangers. The backflush valve is specifically designed to prevent fouling and clogging of the heat exchanger through short intervals.
The high quality of our products is hidden in the details and our long experience. With experience from leading companies across the UK and Europe, we are a proven reliable business partner.

Why Ekström & Son?

• We specialise in tailor-made units that are optimised according to application and the customer’s requirements
• Higher production capacity and lower maintenance costs are achieved through Ekström & Son’s Smart Loop backflush valve with customer references from around the world

References:

Shell, BP Ltd, Amec Foster Wheeler, Johnson Matthey

Elgocell is a manufacturer and supplier of super-insulated pipework for heat networks. An innovative approach in combination with the company’s extensive experience, impetus and unique specialist expertise has resulted in innovative, environmentally friendly solutions for the heat distribution segment with extremely low heat losses.

Our offer: Low temperature heat distribution

We design, develop and distribute culvert systems and technical insulation for underground pipes that give a long-term financial and environmental benefit throughout the entire life cycle. Elgocell offers a complete solution – everything from planning and procurement to implementation and installation. We assist our clients throughout a project, from pre-study, network design to construction for optimal efficiency of the network with minimal heat loss.

Why Elgocell?

• Get long-term financial and environmental benefits throughout the entire life cycle
• Cut costs by reduced heat losses in distribution
• Support throughout the project with detailed network design for optimal efficiency of the network

References:

Skanska Sweden, Sharc Energy, Arrow Energy Ltd, E.ON, Bio-Nordic, AECOM, ÅF Consult

Elvaco is a complete supplier and manufacturer of metering products and cloud services.

Our products and services are used for energy-efficiency, billing and statistics by thousands of companies around the world within district heating, water, real-estate, electricity, gas and many other industries.

Elvaco develops and produces open end-to-end solutions for utility metering, aiming to support our customers to develop their sustainable business.

We are specialized in energy connectivity and infrastructure, from meters and sensors to cloud-based systems and services. The communication standards we work within is M-Bus wired and wireless, LoRa and NB-IOT where we also have a streamlined One Touch Commissioning concept to simplify all integrations.

Key products & functionalities in UK & Ireland

• Our wired and wireless M-Bus infrastructure for fixed network and GSM/GPRS/LTE with modules for wired/wireless communication.
• We develop and produces modules for LoRa communication for Diehl Metering, Kamstrup, Landis+Gyr and Itrons heat meters.
• M-Bus and LoRa temperature and humidity sensors are growing rapidly.
• One Touch Commissioning concept with mobile application for commissioning and do readouts via NFC for all our IoT devices and some M-Bus infrastructure products.
• Our manufacturer independent I/O module over M-Bus for prepayment.
• Cloud service Elvaco EVO to collect, visualize and analyse meter data.
• We work with big utilities and services providers all over UK and on Ireland. They are using our products to collect, visualize, analyse and export meter data into our cloud service Elvaco EVO or to their own head end system (HES).

Energy Opticon is, with its unique software Energy Optima 3, since 1989 one of the largest suppliers of specialised economical computer optimisation, accurate load forecasting and trading support tools for energy companies. Our long experience, know-how, together with our cooperation with our customers are trademarks to the company. Our staff is constantly striving for a friendly, positive and competent treatment of clients. Energy Opticon is widely represented through our many customers and our large international partner companies.

Our offer: smart software for heat networks optimisation

Energy Optima 3 is a very powerful decision support software, which provides a common basis for the planning of energy production and energy trading.

The main functions of the tool are:

• Economical Production Optimization
• Load and Price Forecasts
• Easy Trading Support
• Smart Optimization of Heat Networks
• Advanced Reporting and Follow-up (Business Intelligence).

With Energy Optima 3 it is also possible to economically optimise the power plant’s yearly quotes for emissions to the air. Optimisation of maintenance periods and the future market prices for electricity are also taken into consideration here.

Smart energy companies invest in Energy Optima 3, and return of investment is normally within one year.

Why Energy Opticon?

• Increase incomes, e.g. reduction of variable operation costs with 2-10 % through economical production optimisation.
• Save time and increase work efficiency with easy reporting functions and an advanced decision support tool for production planning.
• Maximum profit with optimization of CO₂ and NO_X

References:

About 50 energy utility companies from many countries in Europe, among which are E.ON and Vattenfall in Sweden, Stadtwerke Schwerin in Germany, Industrielle Werke Basel in Switzerland, CTR/VEKS (Copenhagen) in Denmark, and many more.

ENERIQ develops and provides intelligent energy solutions to cut costs, reduce carbon and create more liveable and smarter cities

Our offer: ENERIQ will optimize energy operations to lower environmental impacts

ENERIQ develop and provide smart solutions for optimization of district energy networks to utilities and energy operators in Europe.
ENERIQ cooperates with leading actors such as NODA, EcoPilot, Cetetherm and ÅF for full-scale implementation and operation of smart energy solutions.

Why ENERIQ?

By cooperating with ENERIQ, energy operators will gain benefit and support in all parts of the intelligent energy value chain.
The ENERIQ model:

• Evaluation. Define and calculate the benefits of implementing intelligent optimization in different parts of the eco-chain
• Tools. Implement and utilize from existing intelligent energy services or customized solutions based on research findings
• Management. Co-drive with the customer during the entire process, from implementation to operation
• Financing.

References:

Ennatuurlijk

E.ON Energilösningar is a subsidiary of EON Sverige and focuses on customer solutions such as energy sales, energy efficiency, district heating and cooling and the development of the new energy system. The goal is set to be 100 % fossil free by 2025 and several solutions are being developed to facilitate this ambition, where new heating and cooling solutions are an essential part. Today, E.ON Energilösningar delivers approximately 5 TWh hours of district heating to customers in Sweden, but do also have extensive activities in the area of city quarter solution. ectogrid™ is owned, built and operated by EON Energilösningar.

ectogrid™ is an energy system that is based on available energy sources and not dependent on combustion. It is a very efficient way to electrify the heating sector and at the same time provide cooling. The control of the system also creates flexibility and is integrated with the electric distribution system and market. The build out of renewables requires flexible loads and ectocloud™ will support the integration. Both France and UK will have increasing demands of comfort heating that will be provided by ectogrid™ as well as the heating, balancing as much energy needs against each other as possible.

With our valves and actuators for heating and cooling applications, we help property owners reduce their energy costs without sacrificing comfort, thus reducing the world’s environmental impact.

Our offer: Lift, linear and rotary shoe valves and actuators

Our core areas are rotary valves, actuators, controllers and thermostatic valves intended for use in heating and cooling in hydronic systems. ESBE complete motorised rotary valves and actuators regulate the heating comfort of millions of households guaranteeing reliable, energy-efficient operation for many years to come. The indoor and outdoor sensor controlled valves are both delivered with constant temperature regulators. Our thermostatic control units ensure a safe tap water system by preventing legionella bacteria and scalding.

Why ESBE?

• We are the modern partner in gaining control over safety, comfort and energy saving
• Our valves and actuators are high quality products all produced in Sweden
• ESBE has a long tradition of market presence across the world

References:

Bosch, Vaillant, Enertech and more.

Energy Save has an already established business in the rapidly growing heat pump market. With new patented scalable products and digital solutions, which drastically reduce energy costs and CO2 emissions for both the construction and real estate sectors, the company has great potential for expansion when society strives for a smaller climate footprint. With Energy Save’s patented products, energy savings of 40-70% are achieved. Authorities and the EU are increasingly demanding energy savings and green alternatives, clearly showing that Energy Save’s products are well timed.

Why Energy Save?

• Cost-effective heat pump systems that reduce both energy consumption and climate impact
• Compatible with all types of heat sources
• The energy balance between electricity and heat is optimised through smart control systems, which is important in the energy transition that must be made
• A secure and established company with sales in 18 countries in Europe

References

UCO (Skanska), Swegon, Onninen

With more than 40 years of expertise in the energy sector, FVB is an internationally leading partner and consultant in the development of heat networks. As a consulting firm specialised in heat networks, we have the experience and technical knowledge to provide our clients with a customised energy solution based on their needs.

Our offer: A reliable partner and leading technical consultant

We offer our clients support during the entire development of a heat network business, from conceptualising, construction and commission of the network. We do not only provide our clients with technological expertise, but also support in building a long-term sustainable business model, allowing our clients to utilize their network at low energy costs.
FVB provides a 360 approach that covers all aspects related to the development of a heat networks business; the engineering and technical specifications, business assessment as well as sales and marketing. Our expertise lies in both combined heat and power solutions (CHP), power generation, biomass combustion for thermal production, geothermal neat networks, deep water cooling and thermal energy storage to mention a few.
Our international and extensive experience includes combustion of woody biomass in heat-only boilers and steam turbine CHP systems, biogas production including design of fuelling stations, earth energy and low-grade effluents such as heat sources and sinks, deep water cooling and thermal energy storage to mention a few.

Why FVB?

• We are specialised in heat networks, with an extensive experience and technical knowledge to provide our clients with a customised energy solution based on your needs.
• We assess a project with a 360 approach that covers all aspects related to the development of heat networks to build a long-term sustainable business model
• Leading partner and consultant in the development of heat networks

References:

Private and public energy operators e.g. E.ON, Fortum, Gothenburg Energy and local consultants e.g. Craighall Energy

We deliver reliable, all year-round heating by using burners built to be supplied with inexpensive wood chips and pellets. Using wood chips as biofuel makes GotFire not only an easy but also an environmentally-friendly way of heating domestic houses and commercial buildings.

Our offer: Biofuel burners

We produce everything from single burners for wood chips or pellets to complete heating systems with storage and smoke canals. Whatever we make, it can be customised to your needs and at a low price. The systems require little operational costs as the heating process is automatically monitored through use of a photo-cell, keeping maintenance costs low.

Why GotFire?

• Cost efficient and easily maintained heating all year round
• Elimination of risk of boiling and tar build-up due to ignition and extinction function
• Compatible with other energy sources such as solar cells

Range:

12 – 600 kWh

References:

In the UK, mainly parks and manors e.g. http://www.parkfootullswater.co.uk/, http://www.grimstonpark.com/, http://www.horningtonmanorholidaylets.co.uk/

HL Hydronics offers a complete range within pressure maintaining and air separation for liquid heat systems. HL Hydronics is a company with experience from the past and products designed for the future. We constantly develop and re-think old solutions to be able to provide our customers with more efficient products that do not require any compromise and add value.

Our offer: pressure control and air separation for liquid heat systems

We have created a new standard for pressure maintaining with a built-in motorised valve which gives a smooth pressure maintenance and keeps the variations to a minimum. It also allows a hysteresis of 0,2 bar. Our pressure maintaining device is a perfect match together with our vacuum de-gassing unit which is developed with the same intentions.

All of our products are developed and manufactured in Sweden. The products we offer are designed to be as optimal and energy efficient as possible for the system and also the product itself. It’s important for us to create value for the complete chain from standardized manufacturing to easy installation to a stable and reliable product in the system with low maintenance cost.

Why HL Hydronics?

• Vacuum air separator is among the most efficient on the market with a vacuum pressure at -0,8 bar.
• Our device will definitely extend the lifetime of your liquid heat system.
• Simple installation, high efficiency, long service cycles and low wear and tear rate due to special programs that keeps unnecessary pump starts to a minimum.

References

• Customers: Ariterm, Solar, Dahl, Oskarshamns Energi, SaltX etc.
• Projects: LHL Gardermoen, UNN PET-center Tromsö, SKF HQ Gothenburg etc.

Jernforsen is one of Europe’s leading companies within the field of bioheating technology, offering development, manufacturing and service of biomass combustion plants ranging from 2 – 35 MW.

Our offer: Biomass combustion plants

We provide combustion equipment for heat networks, CHP and industrial plants. These can be supplied as component sections or as complete turn-key solutions. The boilers produce hot water, saturated- or superheated steam. We design, construct, assemble and commission the equipment from fuel storage to chimney.
Our combustion system is continuously developed in collaboration with scientists and experts to meet increasingly stringent environmental requirements, and also to be able to offer you a facility with the market’s lowest operating costs.

Why Jernforsen?

• High automation level for stable, unmanned operation of entire heating system
• Our engineers continuously keep an eye on our clients major combustion processes remotely and advise the operators if needed
• Our comprehensive control systems are smartly developed without being overworked

Range:

2 – 35 MW

References:

Public and private energy operators such as E.ON, InnTre AS, Eidsiva Bioenergi AS. In the UK, sawmills, district heating schemes and universities: St Andrews, BSW Timber

We are a research-based company and we believe profitable feedstock is the key to a profitable and sustainable energy supply through a biomass cogeneration application.

Our offer: Smart biomass cogeneration applications

At Meva Energy we develop highly efficient small-scale CHP stations based on biomass gasification.

Our plants are of industrial size and can replace traditional heat boilers with a more refined feedstock utilisation producing both power and heat.
As biomass costs represent the lion’s share of any operational expenditure, our system is adapted to using not only conventional wood fuels such as pellets but also really low cost second generation biomass. This includes saw dust, agricultural husk and industrial fibre residue. Meva Energy’s VIPP-system (Vortex Intensive Power Process) is a complete system from gasifier to syngas cleaning for production of renewable fuel gas which is fed to a power engine genset for distributed production of power and heat.

Why Meva Energy?

• Our small and decentralised stations reduce distribution losses of power and heat to a minimum
• The technology is eligible for the renewable heat incentive (RHI) and for Contracts for Difference (CfD)
• Low capital investment and operational cost, with possible payback times in less than 5 years

Range:

1-5 MWe and 2-10 MWth.

References:

Lund University, Pite Energy

Midroc-The Automation and EPC contractor.

It doesn´t matter if our customers are refining oil, mining for gold, roasting coffee, producing energy or manufacturing city jeeps. Everywhere in which industrial production is trimmed, streamlined and developed, Midroc Automation has a natural and important role to play. There are few suppliers in the world whom get the confidence to handle comprehensive solutions in large, complex industries.

Midroc are one of them.

Thanks to our financial strength and a project capability beyond the usual, we take responsibility for the complete supply-chain. Of people, assembly solutions and mechanics, with plant design, power construction and good corporate cross-border cooperation. This enables us to deliver higher productivity and an industry with better profitability over time.

With one single contract.

References:

E.ON, Fortum, Vattenfall, Volvo, Freeport-McMoRan, LKAB

At Mittel, we make sure your district heating system works at maximum efficiency by detecting and eliminating weak points in the network.

Our offer: Detecting and reducing heat loss

We are a technology provider offering joints and leak detection for pre-insulated pipes. Nearly three decades of hands-on experience have enabled Mittel to develop technologies that significantly extend the useful life of pre-insulated pipes.
Mittel TSC® stands for joints that are as strong and durable as the pipe. Joints often corrode due to pressure, damp and wear, resulting in huge energy losses and costly repairs, but with Mittel TSC this can be kept at a minimum. Mittel Pipeguard™ is the world’s most competent system for round the clock surveillance of pre-insulated pipes. Both these technologies dramatically extend the useful life of pre-insulated pipes.

Why Mittel?

• Lower life-cycle costs and operational expenses
• Improved heat supply due to risk reduction
• Enables you to have higher level of control over the network

References:

E.ON, Veolia, PinnaclePower and Engie

Ngenic creates a platform for the smart home and has chosen to start the revolution with intelligent control of indoor climate.

Our offer: smart home platform

The company was founded in Uppsala in 2010 and today there is also a Stockholm office. Ngenic Tune is a “smart thermostat” for single family homes with water based heating. It saves energy, improves comfort and gives the user control via an app. The possibilities are enormous.

Modern control algorithms and sensor systems allow better adoption to individual home characteristics and better comfort, as well as modern control with a connected home. Ngenic started with that in mind and have a lead position in the single family home segment in the Nordics. Within district heating we are the only system on the market today with proven benefits both for end user as well as district energy provider.

Why Ngenic?

• The only DIY system for water based heating system optimisation.
• Saves energy with increased comfort level with intelligent ECO-drive of heating
• Enables demand side management without compromising on comfort or productivity
• Customer dT maximization while maintaining a minimal peak load

References: Upplands Energi, Sandviken Energi, Tauron

NODA develops and provides intelligent energy systems for energy optimisation and system-wide surveillance for both energy companies as well as building companies.

Our offer: Software for energy optimisation

With a background in data science, we develop and provide smart solutions for optimization of district heating networks and for energy efficiency in buildings.
NODA Smart Heat Grid Solutions™ enables operational heat load optimisation of utility heat networks via the most intelligent energy system on the market. By using big data from buildings and auto-analytics systems, utilities can be proactive to peak load demands and optimise the operational behaviour of the heat load.
NODA Smart Heat Building Solutions™ measures, analyses and optimises the energy consumption by lowering the energy need in commercial buildings, creating long-term energy sustainability and increasing the value of the property. Historical and real-time data is shown on our customer web portal where facility operators and building owners can follow the behaviour of the building and act upon the information when needed, for instance if unwanted deviations occur.

Why Noda?

• By using big data, Noda can lower the average energy demand in a building by 10% and proactively reduce peak loads in the grid
• Due to direct integrations or retro-fit solutions our offering operates with existing building management systems
• Our intelligent energy services will decrease operational cost and lower the CO2 emission impact on the environment.

References:

E.ON, Fortum, Veolia

NordHeat dates back to 1972 when Stig Söderström took over the company ‘Stanex’ and since 2005 owned by Karrberg Konsult in Kristianstad, south Sweden. We have designed and delivered more than 15.000 heat exchangers. NordHeat’s office and workshop are located 1.5h from Copenhagen Airport by train.

Our offer: Tailor-made products for the process and heat networks industry

Nordheat provides tailor-made products for the process and heat networks industry: heat exchangers, electric heaters, direct steam injectors, and other key equipment for your plant. We both design and deliver solutions for condensers, evaporators, boilers, preheaters, and steam injectors. As experts in our field NordHeat is often contracted for thermal design, optimisation, and simulation of heat exchangers. Our work is assisted by the latest design softwares, such as Aspentech.

Why Nordheat?

• 30-year experience from the Scandinavian heat networks and district cooling market
• Made in Sweden: Design and assembly of heat exchangers in our own workshop
• Easy to work with: Representative office in the UK (London)

Range

0.5-50MW (shell & tube heat exchanger)

References

Foster Wheeler, E.ON, Vattenfall, Göteborg Energi, Oslo Energi, Norbulk Shipping UK, Skanska, Jernforsen, Midroc

Nordic Heat is an independent and not for profit peer-to-peer advisory service aiming to support the development of district energy and waste to energy (W2E) solutions in new markets. We do this by transferring the extensive know-how and experience developed in Scandinavia over the past 50 years. The Nordic Heat network has been established by a group of publicly owned Swedish energy operators, all with a long and proven track record of installing and operating commercial district energy systems.

Our offer: independent and experienced peer-to-peer advisory service

The overriding ambition of Nordic Heat is to assist new entrants to the district energy sector in the challenging process of bringing projects beyond feasibility studies and into business planning, financing, installations and operations. Based upon their long experience and extensive know-how, the Nordic district heating operators involved in Nordic Heat will be able to assist project teams with second opinion, peer-to-peer advice, reference cases, bench marks, selection of technologies and suppliers, training, support in commissioning, inspiration and leadership. Performance, total cost of ownership and price are always the key criteria.

Why Nordic Heat?

• Fees related to the services are adjusted to cover the costs related to the mission and to further develop the content, reach and scope in the services provided
• The advise we give is completely unbiased when it comes to selecting suppliers of technologies and services

References:

Stoke-on-Trent City Council, Bristol City Council, The London Borough of Haringey, The Department of Business, Energy and Industrial Strategy (BEIS), Services Industriels de Genève, Belgian Waste to Energy Association (BW2E)

NordiQ offers Smart control systems and substations for residential networks for small or medium sized property owners who wish to run a heat network with both low energy and maintenance costs.

Our offer: Smart control systems and substations for residential networks

We provide heat control systems and substations for smaller residential buildings. The products are designed to heat in a more even and consistent way which increases comfort and reduces energy cost. Our patented solutions are part of our integrated approach; meaning we take care of everything from planning and conceptualisation to installation and operation. Our offer covers and integrates substations, regulation, heat pumps and ventilation.

Why NordiQ?

• Save 10 -15% on energy costs for multiple residence buildings
• Increased living comfort thanks to our unique thermal balancing method
• All patented solutions are adapted for the UK and offered as a complete turnkey solution

Range:

Minimum 8 kWh, no upper limit

References:

Larger residential buildings

OsbyParca is one of Sweden’s leading manufacturing energy companies offering a complete range of boilers for heat and steam through oil, gas, electricity and solid fuels. Our clients range from private and public energy companies, process industry, property developers and housing associations.

Our offer: High tech, efficient solid fuel boilers

Osby Parca offers a complete solid fuel range from 100 kW to 8 MW. The scope of supply includes boilers for wood pellets, wood briquettes, dry wood chips (<35% moisture content) and moist wood chips (>35-60% moisture content) depending on the choice of boiler or furnace.
The solid fuel boilers are built with vertical flue gas tubes with turbulator cleaning. This treatment is fundamental for high efficiency rates and long service cycles. Our boilers come with controls that permit automatic ash discharge and fuel feeding. Intelligent control systems maintain the operation levels at optimal levels for efficient combustion and low wear rates. Cleaning of the convection tube package and ash handling are carried out automatically with programmed intervals.

Why OsbyParca?

• The solid fuel boilers are built with vertical flue gas tubes with turbulator cleaning. This treat is fundamental for high efficiency rates and long service cycles of +25 years
• High efficiency rates, long service cycles and low wear rates due to intelligent control system
• All products are approved according to the exigent Pressure Equipment Directive (PED)

Range:

100 kW to 8 MW

References:

E.ON, Solör, Affärsverken, Oskarshamns energi, IKEA, LKAB, NCC, Swedavia, Göteborgs energi, Jönköpings energi, Vasa energi, Tierps energi, Ronneby Miljöteknik etc and entrepreneurs like AKJ, Pannprojekt, Jernforsen, Värmeprodukter, AKJ, HotAB, Bio-Geo Ltd

Petro Bio has taken on the environmental challenge to carefully convert a wide range of fuels into energy for industrial and commercial usage. Petro Bio is supplying burners and combustion systems, including after sales service.

Our offer: Burners and combustion systems, including after sales service

We offer everything from external fuel processing to flue gas cleaning and ash handling.
Our key competences lie within flame combustion of solid bio fuel (bio powder) and retro fitting in oil/gas or coal boilers. All our burners have a high capability (peak load use). We supply our customers with a complete services offering, including fuel handling and flu gas cleaning.
Each burner is manufactured individually and adapted to meet the customer’s specific requirements in terms of performance characteristics, type of fuel, etc. For example, the Petro Lance Burner with a swing out design and a protective door is very well suited for the harsh environment in a waste incineration plant. In addition to the hardware, we provide service and spare parts for all of our installations.

Why Petro Bio?

• Customer designed burners and controls
• Increased customer profitability through our vast experience and technical know-how
• Reliable supplier delivering uniquely designed and economical solutions

Range:

2-100 MW

References:

Skanska, Göteborg Energi AB, Dalkia / Trelleborg Energi, Hafslund (Oslo)

Powerpipe is a Swedish manufacturer of pre-insulated pipes and fittings for district heating and cooling. Our edge in the different market is our flexibility, speed of delivery and high customer orientation. The company started in 1986 and has been in the UK since 2012. We are the leading manufacturers in Sweden and Norway and have significant market shares in France, Finland, Denmark and the Middle East.

Our offer: Pre-insulated pipes and fittings

We have the full range of products for the total distribution system with the best quality and everything produced and certified according to the European standards for DH and DC.
At Powerpipe we always support our clients during installation and as a supervisor during construction. This is especially important regarding design, practical handling of products and education about the jointing process.

Why Powerpipe?

• Our pre-insulated pipes for heat networks can reduce energy losses by 10%.
• We support our clients with education and training services in all our installations
• We maintain high flexibility, service and speed of delivery

References:

Engie, E.ON, Aberdeen Heat and Power and a lot of different contractors.

Delivered to projects in London, Newcastle, Coventry, Birmingham, York, Southampton, Bristol, Leicester and more.

SaltX Technology is a Swedish technology and engineering company. SaltX is focusing on building thermo-chemical energy storage solutions based on abundant, recyclable and energy dense limestone-based materials.

Our offer: Green, economical and safe energy storages

SaltX can offer a green, economical and safe energy storage system with well-proven technology that can be used for many years.  The thermo-chemical storage is charged with renewable energy and can be dispatched when needed, as in steam or in electricity.

The solution enable a shift into renewables by distributing the energy at the right time in a large scale, a city solution!

Why SaltX?

• Enabling high temperature steam production up to 450°C
• Scalable size suitable for a wide range of customers needs
• High energy density ensures compact and durable solutions where space is limited

References:

An energy storage pilot plant has been deployed at Vattenfall’s CHP plant in Berlin. Filled with nanocoated salt, manufactured by our suppliers Nordkalk and Wacker, it demonstrates our technology and scalability.

Sulzer specialises in pumping solutions, rotating equipment maintenance and services, separation, reaction and mixing technology. We create reliable and sustainable solutions for oil and gas, power and water industry. Combining engineering and application expertise, our innovative products and services add value for and strengthen the competitive position of our customers. Sulzer serves clients around the world through a network of over 170 locations in more than 40 countries.

Our offer: Pumps, agitators, mixers, compressors, service and technology

Sulzer offers pumps for feed water applications, high pressures and temperatures as well as condensate pumps, cooling water pumps and distribution pumps. A variety of pump sizes in a variety of material meets the most demanding applications.

Why Sulzer Pumps?

• Reliable partner with over 170 locations in more than 40 countries
• Large product assortment with a variety of pump sizes and materials, fit to meet the most demanding applications

Range:

Pumping capacity up to 200 °C and up to 10 000 m3 per hour

References:

Contact us directly for references

Sweco is a leading architecture and engineering consultancy which has been involved in driving the delivery of renewable and lower cost heat through district heating projects for many decades across Europe. The results of our work are sustainable buildings, efficient infrastructure and access to clean water. With 14,500 employees in Northern Europe, we offer our customers the right expertise for every project. We carry out projects in 70 countries annually throughout the world.

Our offer: Partner and technical consultant throughout a project

Our clients who turn to district heating can expect to alleviate fuel poverty for residents, and for those running wider estates and building assets, to benefit from energy security and stabilised future costs.
Our team offers a fully integrated approach from initial energy mapping and master-planning, through to technical feasibility and business case development, design and implementation, commissioning, operations and maintenance, and even network optimisation. We work with private sector clients as well as local authorities and other public bodies supported by the Heat Network Delivery Unit under Department of Business, Energy and Industrial Strategy. We are providing detailed design and engineering as well as supporting the design and build of energy centre design and heat networks for universities, private sector developers, energy service companies and contractors.

References:

Multiple heat networks for universities, private sector developers, energy service companies and contractors across Europe.

SWEP is the world’s leading supplier of compact brazed plate heat exchangers (BPHEs). These products are used where heat needs to be transferred efficiently in air conditioning, refrigeration, heating, and industrial applications.

Our offer: Compact and reliable heat transfer

Our supplies of brazed plate heat exchangers (BPHEs) are compact because they have low weight and a small carbon footprint. They are designed for high-capacity applications and provide reliable and steady performance for demanding industrial and heating applications, such as heat networks. For the past two years, BPHEs have been replacing shell and tube as well as plate and frame (gasketed or PHE) technologies as the most preferred heat exchangers. Our BPHEs are especially sturdy and reliable in being hermetic, compact and helium-tested at the factory.

Why SWEP?

• We offer efficient, reliable, flexible and customised heat exchangers
• Our compact and low weight solutions save space, money and service time
• Already well-proven in millions of applications worldwide

References:

Nya Karolinska, Shard building, Tele2Arena, Hässleholm Energy amongst many more. Read more about or references here.

By using verticalized AI to analyze big data, we support the energy industry taking control of planning, operations, sales, pricing, design and customer relations.

Our offer:

Utilifeed integrate all data from a utility company, providing exact information on real time performance as well as a reliable 10 day forecast. Integration is effortless with a standardized interface alongside the existing system. Hence, no intrusion is made on the existing system. No utility is to small or to large as the Utilifeed solution is infinitely scalable to suit all sizes of an infrastructure. Cost savings by utilizing fault detection only, result in a payback of our system within months.

Why Utilifeed:

• Substantial cost savings through efficiency gains in business, the energy system as well as improving customer relations.
• True digitization of all data flows from all parts of the energy company, including metering, market and sales, distribution and production.
• Fully verticalized with services into district heating as well as power grid, water management, energy services and gas distribution.
• Improved customer communication by in-depth understanding of user patterns and behavior as well as new product offerings to the customers of the utility, e.g. real estate owners.
• Proven service with 4 years of customer integration.

References

International customers and partners to date are E.ON, Fortum, Vattenfall, Agrar Plus and SAMPOL

Vitec is a leading supplier of simulation tool for district heating/cooling grids in Europe. For over 30 years Vitec have marketed essential tools for the energy sector, with GSS NetSim being one of them.
At Vitec we have developed a smart software application that provides current and future insights into your heat network, whether in the design, roll-out or operational stage. For over 30 years we have marketed essential tools for the energy sector and our simulation software is now a leader in the market.

Our offer: Smart software for a modern and optimised heat network

Our offer consists of Grid Simulation Software (GSS) applications NetSim and Aiolos Forecast Studio. The Aiolos software platform handles load forecasts for both electricity and heat networks while NetSim simulates the heat network in order to evaluate parameters such as pressure, velocity, temperature, flow, etc.

Why Vitec?

• Our solutions make it easier to design and build a smart and profitable heat network
• All software tools are developed from a deep knowledge in software user interface and district heating
• We have a strong track record with over 170 energy utilities using our products today

References (UK):

E.ON, Brookfield Utilities, ARUP, Sweco, WSP, PinnaclePower

Wideco offers one of the world’s most effective concepts for preventing, detecting and fixing leakage in various types of piping.

Our offer: Leak detection and network securing

Since 1982 we have developed, manufactured and provided markets worldwide with advanced leak detection systems for pipes, advanced monitoring software applications and water/radon tight pipe penetration seals for concrete constructions.
We supply and install our own, in-house designed online leak detection systems (LDS) and liquid level monitoring systems. The LDS include hardware, software, data hosting and communication – which reduces man hours, increases the heat network investment lifetime, elevates operational reliability and results in great customer satisfaction. The instruments are portable and locate leaks as well as document pipe systems.

Why Wideco?

• Risk reduction and cost avoidance; reduces man hours, increases network investment lifetime, higher operational reliability
• Tested and approved Radon/Water tight seal with short delivery time in all sizes

References:

Vattenfall, E.ON, Öresundskraft, Hafslund, Dolomiti Energia Fiera del Primiero, Skanska

World Thermal Service AB is a Swedish manufacturer of wood powder combustion technology. With WTS powder burners, our customers reduce their global emission of CO2 with over 34 thousand tonnes. WTS has worked worldwide with wood powder combustion for over 20 years. Our core business is all about enabling our customers to make the transition into renewable fuels and at the same time increase their profits.

Our offer: Conversion of fossil fuel burners to renewable, biomass fuel-driven

We are a leading expert in converting oil, gas and coal fired boilers into profitable, efficient and future safe biomass-combustion in both small and large scale plants. We also supply multi-fuel wood powder combustion technology for new installations. The solutions can be found across the globe and are also eligibility for the Renewable Heat Incentive system. Our strong position within this technology area is supported by our involvement in pellet production in both conventional pellet and second generation black pellet.

Why WTS?

• We enable you to make a cost efficient and environmentally friendly conversion of your fossil fuel plant
• Awarded for our outstanding contribution to the development of the Biomass Energy Sector and its market

Range: 3 – 50 MW

References:

Statoil, Cargill, Zilkha, Daikin

ÅF is an engineering and design company within the fields of energy, industry and infrastructure. We create sustainable solutions for the next generation through talented people and technology. We are based in Europe and our business and clients are found all over the world.

Our offer:

Project performance assurance from start to finish- energy production to distribution, connect and control stages, delivery and commissioning. Initial stage studies, energy mapping, financial models to detailed engineering and design, construction management, procurement and legal, to full project management services. EPC services.

Why ÅF?

ÅF bridges the gap between initial phase-feasibility study and commissioning of the heat network. We have extensive and deep experience in developing and implementing heat networks. Through decades of experience of working with district heating and a company core particularly strong in the energy field we have a unique position and confidence in taking on any assignment in the heat& power field.

References:

From global big energy providers and suppliers (E.ON, Vattenfall, Fortum, ABB, Alstom etc.), financial institutions and banks (NEFCO, EBRD, World Bank, KfW, SIDA etc.) to small scale scheme owners, contractors and suppliers within the energy infrastructure field across Scandinavia and Europe.
